SONATA 150 Manual Spread Leg | Floor Hoists

The lightweight, compact Sonata 150 patient lifting hoist is an easy-to-use, everyday lifter that utilises SPACE LINK Technology that optimises patient space by increasing the maximum lifting height of the hoist and enhancing floor lift capability.

SPACE LINK™ Technology

The SPACE LINK Technology is a breakthrough for optimising patient space as it increases the maximum lifting height of the hoist. It also enhances floor lift capability and is compatible with both standard spreader bar and pivot frames.

Lightweight, compact mobile patient lifting hoist
Innovative and ergonomic design
Utilises SPACE LINK Technology for superior patient lifting space

Safe Working Load: 150kg
Base Length: 1005mm
External Base Width: 605mm
Internal Base Width Closed:530mm
Internal Base Width Open: 1010mm
Base Width Adjustment: 3 Position Manual
Under Bed Clearance: 125mm
Minimum Height Spreader Bar: 340mm
Maximum Height Spreader Bar: 1685mm
Average Lift Range: 930mm
Lifter Weight: 39kg
Minimum Storage Height: 1235mm
Under Base Height: 50mm
Max. Hoist Reach: 875mm
Min. Hoist Reach: 555mm
Max. Hoist Reach At Max. Height: 555mm
Min. Hoist Reach At Min. Height: 525mm
Turning Radius: 1080mm
Mass Of Heaviest Part: 16.7kg (Mast Assembly)

SKU	211102022
Model #	SON01
Brand	Allegro Concepts
Shipping Weight	46.0000kg
Shipping Width	0.705m
Shipping Height	0.520m
Shipping Length	1.105m
Shipping Cubic	0.405093000m3
