Featuring 6-wheel fully independent suspension system
ISO/ARTG: AS 3695, AS 3696 & AS 3696.19 (Crash Tested). ARTG Cert: 95730
The Glide Centro features the Active Pozi-Trak system (APT) which is a unique suspension system to increase traction, kerb climbing and acts as an anti-pitch device. Read More
Australian designed and manufactured the Centro is designed to give outstanding stability, flexibility, indoor & outdoor performance and drive capabilities with trouble-free service for many years.
It comes with Active Pozi-Trak System (APT)- 6 wheel full independent suspension system. Manoeurvable, narrow and compact for a perfect blend of indoor and outdoor performance. Long range with 73 amp batteries for all dayt freedom. It is available with electric lift and tilt plus all Glide Centro Electric wheelchairs come with a completely customisable seating platform.
Active Pozi-Trak system
Patented by Glide the APT is a unique suspension system that was developed to enhance the performance of its latest Mid Wheel Drive wheelchair. It is a three functional operation that increases traction on its drive wheels, aids with kerb climbing and acts as an anti-pitch device. The suspension system also eliminates nose dive when descending road side kerbs.
The drive wheels are set positive meaning when the wheelchair is on a level ground a preload of up to 20kg (depending on spring set up type) is on each drive wheel. This unique system greatly improves traction for driving and braking. It also performs extremely well in emergency down hill braking.
The APT is a low maintenance system and has eliminated the need for complex moving parts that need constant servicing or adjustements. Also, with the combination of varying spring set ups, the wheelchair can be fine tuned to suit the needs of the user.
- Available in adult and paediatric versions
- Motors- High quality German motors for Centro - Choice of 2 polo or 4 Pole High torque
- Low seat height (46cm at 0°)
- 50 or 70 amp/hr Batteries capabilities
- 50° Tilt standard
- Vehicle Tie Down points
- Low maintenance with easily accessible electronics
- Turn Circle 980mm (foot plate removed)
- 80mm kerb climbing ability
- 80mm ground clearance
- Compability to most Proprietary Seating systems on the market
Max Recommended User Weight:175kg - AS3695
Seat Width: 31, 34, 37, 40, 43, 46, 49, 52, 55
Chair Weight: 95kg (without batteries and seating)*
Seat Depth: 31, 34, 37, 40, 43, 46, 49, 52, 55
Rear Wheels 6” Solid Castor
Seat Tilt: 4o-50o or 0o-46o
Front Castors: 200 x 50 (8”) Pneumatic castor
Seat Height: 46cm
Drive Wheels: Mid Wheel Drive 3.00 -8 (14”)
Arm Rests: Flip-Up Adjustable
Suspension: Posi-Trak System Leg Rests Swing-away Detachable
Overall Length: 900mm (footplate removed)
Brakes: Electronic and Manual Park
Overall Width: 620mm
Controls: R-Net (Dynamic as an option)
Back Height: 1030mm
Battery: 75 Amp/Hr
*Weight may vary, dependng on configuration
ISO: AS 3695, AS3696 & AS 3696.19 (Crash Tested)
ARTG Cert: 95730
