A lightweight compact mobile patient lifting hoist with innovative and ergonomic design.

The Sonata ELS is an easy to use everyday lifter. With a safe working load of 150kg the Sonata ELS offers an outstanding lift capacity in a small patient hoist.

The Sonata ELS offers all the versatility of the original Sonata, with the added advantage of Electric Leg Spread. This allows for easy of lifter leg adjustement on carpeted surfaces and/or with the heavier client on board.

FEATURES

• The Duracare Sonata ELS is a lightweight compact mobile patient lifter with innovative and ergonomic design
• Easy to use everyday lifter
• Offers an outstanding lift capacity in a small patient hoist
• The Sonata ELS offers all the versatility of the original Sonata, with the added advantage of Electric Leg Spread
• This allows for ease of lifter leg adjustment on carpeted surfaces and/or with the heavier client on board
• Featuring Linak Jumbo Care advanced diagnostic control system
• Powered by LA44 European Standards compatible linear actuator

SPACE LINK™ Technology

• Increases maximum lifting height
• A breakthrough for optimized patient space
• Enhances floor lift capability
• Compatible with standard spreader bar or tilt/pivot frame

SPECIFICATIONS

Base Length: 1100mm
External Base Width Closed: 670mm
External Base Width Open: 1075mm
Internal Base Width Closed: 570mm
Internal Base Width Open: 970mm
Base Width Adjustment: Electric
Under Bed Clearance: 130mm
Minimum Height Yoke: 400mm
Maximum Height Yoke: 1735mm
Average Lift Range: 880mm
Lifter Weight: 41kg
Minimum Storage Height: 1250mm
Under Base Height: 55mm
Maximum Hoist Reach: 865mm
Minimum Hoist Reach: 515mm
Hoist Reach at Maximum Height: 515mm
Mass of Heaviest Part: 21kg
​Maximum User Weight: 150kg
